MSS Series Single Shaft Shredder

MSS Series Single Shaft Shredder



MSS series single shaft shredder is suitable for the pre-crushing of various large materials. According to different material requirements, different cutter rolls can be selected. The correct and proper cutter roll can greatly improve the performance and production efficiency of the equipment. The series can be customized according to different needs, including different feed hopper size, drive power, cutter configuration, and discharge options.



MST series single shaft shredder are high speed shredder machines designed especially for the efficient size reduction of various materials in a single pass. This is ideal machine for processing a multitude of materials including plastics, rubber, copper cable and organics amongst others.





1. This machine is widely used to shred materials that are quite thick and tough such as those wasted junks in the die, large plastic pipes, plastic injection lump packing buckets and splints of the forklift truck and especially for recycling different materials such as plastic, rubber and wood in shredding ways.

2. The knife and rotor can be taken down so that you can clean, maintain as well as protect the machine.

3. The transmission components are connected by a coupling, which reduces vibration, protects the main shaft and the reducer, and does not damage the force.

4. The square blade design on the rotor ensures high cutting efficiency and prevents heat generation. Each rotary knife has four cutting edges, you can continue to use it after 90° rotation when it wear.

5. The wheel gear reducer drive the main shaft, it has the advantages of stable running lower noise and big torque.

6. The material are pushed into the shredding chamber by hydraulic. Independent drive system and solid structure make the running stably.

7. PLC control system and positive and negative rotation as well as the emergency stop can ensure the machine working safely and stably.






Model

MSS-600

MSS-800

MSS-1000

MSS-1200

MSS-1500

Crushing chamber(mm)

600*700

800*1100

1000*1100

1200*1100

1500*1350

Main Motor

 (kw)

18.5-22

30

45-55

75

110

Capacity(kg/h)

300-500

500-700

900-1100

1200-1500

1500-1700

Weight (kg)

1600

2800

3500

4800

6000
